CNLINKO M24 Plug and Socket 10 Pin Aviation Waterproof Power signal Cable Plug Connector

Product Categories

Shenzhen Connectorworld Technologies Co.Ltd.

Contact Now

Name: CNLINKO M24 Plug and Socket 10 Pin Aviation Waterproof Power signal Cable Plug Connector
Brand: cnlinko
Price: 5.17 USD

Place of Origin : Guangdong, China

Brand Name : cnlinko

Model Number : LP-24-C10PE-01-001

Certification : CE,ROHS,CCC,ISO9001

MOQ : 2

Price : $5.17-6.03

Shape : ROUND

IP level : ip68

Type : XLR

Application : Audio & Video

Gender : male and female, Female +male

Keyword : 10 pin power connector

Protection level : IP65/IP67

Pin : 10 pin

Current rating(A) : 10A

Shell & Insulated Parts : High Performance Engineer Plastic

Hardware Matel : Zinc Alloy (pearl hard chromium)

Connecting mode : plug/unplug

Operating voltage : /

Contact Now

In Stock ISO9001 CNLINKO M24 10 pin aviation waterproof power signal connector

Product Description

Specifications

In Stock ISO9001 CNLINKO M24 10 pin aviation waterproof power signal connector

Specifications
Connecting mode	Latching Lock connect
Protection level	IP67
Cable specification	0.15mm² ~ 0.2mm² /26~24AWG
Diameter range	Φ8mm ~Φ14mm
Contact diameter×Qty	Φ1.5x10
Current rating(A)	10A
Operating voltage(AC.V.rms)	/
Withstand voltage(AC.V)1min	2500V
Contact resistance	<30mΩ
Insulation resistance	>500MΩ
Durability	≥500 mating&unmating cycles
Temperature rating	-40°C~80°C
Method of connecting cable	Solder
Prevent the combustion level	UL94-V0
Material
Insulated parts	High performance engineering plastics
Hardware metal	Zinc alloy(pearl hard chromium)
Contact pin	Copper alloy(gold-plated)
Spring	Stainless steel
Sealing	Silica gel
Main characteristics
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
socket with cover
Application industries
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Ship equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery
